Beam Pattern

Sample results for measured beam pattern are shown on a 30-cm grid. The detection pattern is shown for dowels of varying diameters that are placed in front of the sensor

Parameter	Description
A	6.1 mm (0.25-inch) diameter dowel
B	2.54-cm (1-inch) diameter dowel
C	8.89-cm (3.5-inch) diameter dowel
D	11-inch wide board moved left to right with the board parallel to the front sensor face. This shows the sensor's range capability.
