IndiLoRa X Datasheet

Product Overview

IndiLoRa X1 is an ultra-affordable single-channel indoor LoRaWAN® gateway designed for small-scale IoT deployments and legacy industrial system upgrades. Built on the powerful nRF5340 dual-core MCU, it bridges LoRa® sensors with both cloud platforms and local RS-485 networks simultaneously — enabling seamless modernization of existing PLCs, meters, and building automation systems.

With Wi-Fi backhaul, IndiLoRa X1 eliminates the need for Ethernet cabling, making installation fast and extremely cost-efficient in retail stores, warehouses, apartments, hospitals, small factories, and utility rooms. The fanless design ensures silent operation and support for 24×7 monitoring applications.

Supporting AES-128 encrypted communication, OTA updates, MQTT/HTTPS cloud delivery, and direct RS-485 Modbus output, IndiLoRa X1 allows rapid integration into SCADA, BMS, EMS, utility monitoring and more — without replacing existing equipment.

Whether enabling indoor environmental monitoring, asset tracking, energy meters, or low-density sensor networks — IndiLoRa X1 delivers a budget-friendly indoor LoRa® gateway solution that bridges Industry 3.0 with Industry 4.0.

Download Center

📂

Download Datasheet

Download the PDF Version of the Datasheet .

📝

Firmware/SDK

Click here to view the decoders for IndiLoRa X

Key Features

Ultra‑Low Cost LoRa® Gateway Designed for cost‑sensitive IoT installations with compact coverage needs in smart buildings and commercial environments.

Wi‑Fi Backhaul Connectivity Cloud communication using Wi‑Fi no Ethernet wiring required for installation.

RS‑485 Modbus Output Support Direct interface with legacy PLCs, meters and BMS systems for simultaneous LoRa‑to‑wired integration.

Powered by nRF5340 MCU Dual‑core processing with secure and power‑efficient wireless communication.

Focused Single‑Channel LoRa® Operation Ideal for low‑density sensor networks inside controlled indoor areas.

Secure Communication AES‑128 data encryption and TLS‑based secure OTA firmware upgrades.

Plug‑and‑Play Deployment Zero‑touch provisioning using MacCloud for rapid installation by onsite technicians.

Quiet & Low‑Power Design Fanless architecture built for 24×7 uptime in noise‑sensitive environments.

Suited Applications

Small Smart Building Deployments Cost‑efficient indoor LoRa® coverage for energy monitoring, room comfort sensors and building automation in compact areas.

Commercial Retail Outlets Enables IoT connectivity for shelf monitoring, occupancy analytics and refrigeration compliance without wired infrastructure.

Warehouse & Storage Spaces Ideal for indoor asset tracking, stock environment monitoring and automated supply chain alerts.

Hospitals & Healthcare Rooms Adds secure connectivity for patient safety, air quality monitoring and equipment status without major installation work.

Apartments & Residential Smart Homes Facilitates LoRa®‑based water meters, energy monitoring and safety sensors for housing automation.

Legacy Industrial Machine Rooms Provides RS‑485 integration for PLCs and meters, bridging Industry 3.0 devices with modern IoT cloud systems.

Hotels & Hospitality Spaces Supports smart room solutions and maintenance alert systems without disturbing infrastructure aesthetics.

Data Center & IT Racks Perfect for localized monitoring of temperature, humidity and access conditions inside server environments.

Technical Specification

General
Specifications

Part Order Number

IndiLoRa X

Product Brand

Macnman Technologies Pvt Ltd

Hardware
Specifications

Processor Type

nRF5340 Dual‑Core Bluetooth® LE & LoRa Gateway MCU

Number of Cores

Dual‑Core (1× Application + 1× Network Core)

Clock Speed

128 MHz (Application Core) / 64 MHz (Network Core)

Memory Size

512 KB RAM

Memory Architecture

Low‑Power Multi‑Core Shared Memory Architecture

Internal Flash

1 MB On‑Chip Flash + External Flash Support

USB Port

Debug Interface (Bottom of Enclosure)

Connector Type

USB Type‑C

Interface Protection

Surge Protection Enabled

LoRa
Specifications

Compatibility

Macnman LoRa Nodes & Controllers

Supported Frequency Bands

IN865

Channel Support

Single‑Channel (1 × Uplink / 1 × Downlink)

Data‑Rate

Fixed Data‑Rate – No ADR (single‑channel limitation)

Tx Power

+23 dBm @ IN865/868 MHz    +20 dBm @ 915 MHz

Rx Sensitivity

Down to –136 dBm @ SF12, BW 125 kHz

Antenna Type

External High‑Efficiency LoRa Antenna

Device Capacity

Optimized for Localized Indoor Installations with Small Node Density

Native
RS485 Output

Interface Type

RS‑485 Half‑Duplex

Protocol

Modbus RTU (Slave Mode)

Baud Rates Supported

9600 / 19200 / 38400 / 57600 / 115200 bps (Configurable)

Data Format

8‑N‑1 (Default) / Configurable

Command Processing

Receives LoRa® sensor data and responds to host read commands via Modbus Holding Registers

Isolation

Built‑in surge and ESD protection for industrial environments

Connector

2‑Pin Terminal Block

Integration

Compatible with Industrial PLCs, BMS, HVAC Controllers and SCADA systems

Backhual
WiFi

Bands

2.4 GHz ISM Band

5 GHz ISM Band

Standards

IEEE 802.11 b/g/n, 802.3, 802.3u, 802.11e-compatible bursting

Modulation Schemes

BPSK, QPSK, 16 QAM, 64 QAM

Security

WEP, TKIP, AES, WPA, WPA2

Antenna

External Antenna Integrated in Enclosure

Backhual
Cellular Lte*

Cellular Bands

B1 / B3 / B5 / B7 / B8 / B20 / B28

Standards

3GPP LTE, IEEE 802.3, IEEE 802.3u, 802.11e-compatible bursting

Modulation Schemes

BPSK, QPSK, 16‑QAM, 64‑QAM

Security

WEP, TKIP, AES, WPA, WPA2

Antenna

Internal Antenna Integrated in Enclosure

Supported
Protocols

Supported Protocols

MQTT

HTTP

HTTPS

Physical
Characteristics

Power Supply

9-36 V PoE

Operating Temperature

-40°C to +80°C

Humidity Range

0% to 100% RH (non-condensing)

Ingress Protection

IP35

Housing Material

Aluminium

Color

Matte White

Weight

~120g

Mounting Options(Brackets)

Pole Mounting / Wall Mounting

Certifications &
Compliance

WPC

Compliant

RoHS

Conforms to RoHS directive

Security &
Encryption

Data Encryption

AES-128 end-to-end encryption

Authentication

OTAA activation modes (Nodes)

Firmware Protection

Secure boot and signed OTA updates

IndiLoRa X Variants

Variant Name	Power Source	Wifi	Ethernet	Cellular	Ideal For
IndiLoRa X1	12–24 V (Power)	✔️	✖️	✖️	Ideal for small indoor networks with stable Wi-Fi backhaul such as offices, retail stores and hospitality environments.
IndiLoRa X2	12–24 V (Power)	✔️	✖️	✔️	Designed for mission‑critical deployments where Ethernet, Wi‑Fi and LTE failover ensure uninterrupted connectivity in industrial and multi‑site facilities.

What's in the box ?

Make sure box contains following items before installations

note

Accessories must be purchased separately & may not be included in the box.

Product Dimensions
