MacSync-L-CO2X Datasheet
Product Overview
MacSync-L-CO2X is an advanced LoRaWAN® CO₂ indoor air‑quality monitoring sensor designed for smart buildings, workplaces, schools, hospitals, and industrial indoor environments where air quality and ventilation performance directly impact safety, comfort, and productivity.
Powered by a highly accurate NDIR CO₂ sensing module with automatic calibration, it continuously measures CO₂ levels and supports temperature & humidity monitoring — delivering complete IAQ (Indoor Air Quality) intelligence for demand‑controlled ventilation and energy‑efficient HVAC automation.
Featuring long‑range LoRaWAN® wireless communication, multi‑year battery life, and embedded AES‑encrypted data security, MacSync‑L‑CO2X eliminates the need for wired infrastructure — making it ideal for both new and retrofit deployments.
The device includes BLE connectivity via Maya App for fast provisioning, diagnostics, and OTA configuration — without requiring professional install tools. Its sleek IP65‑rated enclosure, low‑profile wall‑mount design, and silent operation make it perfectly suited for public indoor environments.
From classroom ventilation compliance, office occupancy analytics, healthcare safety monitoring, to optimized industrial workspace conditions — MacSync‑L‑CO2X transforms indoor spaces into intelligent, wellness‑driven, and energy‑efficient environments.
 |  |
|---|---|
 |  |
Download Center
Download the PDF Version of the Datasheet .
Click here to view the decoders for MacSync-L-CO2X
Key Features
High‑Accuracy NDIR CO₂ Sensing Reliable ppm monitoring with intelligent auto‑calibration for long‑term stability.
Temperature & Humidity Measurement Combined IAQ insights for HVAC efficiency and comfort analytics.
LoRaWAN® Long‑Range Wireless Connectivity Ultra‑low‑power wireless communication enabling multi‑year battery life.
Indoor‑Optimized Design Sleek IP65 enclosure for offices, workplaces, classrooms & public buildings.
Event‑Based CO₂ Alerts Threshold reporting for ventilation control and indoor air safety compliance.
BLE Configuration via Maya App Fast provisioning, diagnostics & OTA parameter updates using mobile.
Supports Smart Building Automation Enables ventilation optimization and occupancy‑based control strategies.
Secure Encrypted Transmission AES‑128 data protection ensures privacy and network‑grade security.
Works with All LoRaWAN® Networks Full compatibility with commercial, campus & city infrastructure.
No‑Wiring Installation Ideal for retrofit projects and remote indoor IAQ upgrades.
Suited Applications
Smart Building IAQ Monitoring Continuous CO₂ tracking for offices, commercial buildings, airports & public facilities.
Schools & Educational Institutions Ensures healthy ventilation levels for classrooms, labs & auditoriums.
HVAC Automation & Energy Savings Demand‑controlled ventilation based on occupancy-driven CO₂ insights.
Hospitals & Healthcare Facilities Air‑quality compliance in wards, ICUs, waiting halls and clean areas.
Cold Storage & Pharma Warehouses Maintains regulated CO₂ exposure limits for personnel & stored goods.
Factories & Industrial Workspaces Worker health assurance with real‑time CO₂ risk notifications.
Retail Shops & Fitness Centers Occupancy‑aware ventilation for comfort and operational efficiency.
Hospitality Spaces Hotels, restaurants & cafes ensuring a healthy guest experience.
Smart City Infrastructure Monitoring CO₂ levels in public libraries, transit hubs & community centers.
Technical Specification
General
Specifications
Part Order Number
MacSync-L-CO2X
Product Brand
Macnman Technologies Pvt Ltd
CO₂
Measurement
CO₂ Measurement Range
400 ppm – 2,000 ppm
400 ppm – 5,000 ppm
Accuracy
± (50 ppm + 5% of reading)
Repeatability
± 10 ppm
Response Time (T90)
≤ 60 seconds
Accuracy Drift (per year)
± (5 ppm + 0.5% of reading)
Sensor Type
NDIR (Non‑Dispersive Infrared) with Auto‑Calibration
Calibration
Factory calibrated
Temperature
Measurement
Range
-10 °C to +60 °C
Accuracy
± 0.8 °C
Resolution
0.1 °C
Accuracy Drift
< 0.03 °C / year
Sensor Type
Integrated Temperature Sensor
Humidity
Measurement
Range
0% to 100% RH (non‑condensing)
Accuracy
±3% RH (10%–90% RH), ±5% RH (<10% or >90% RH)
Resolution
0.5% RH
Calibration
Factory calibrated
Wireless
Transmission
Wireless Protocols
LoRaWAN® (v1.0.4)
Macnman MacTalk Protocol
Antenna
Internal high-efficiency antenna
Supported Bands
IN865 / RU864 / EU868 / US915 / AU915 / KR920 / AS923-1/2/3/4
Tx Power
23 dBm @ 868 MHz / 20 dBm @ 915 MHz / 19 dBm @ 470 MHz
Sensitivity
-137 dBm @ 300 bps
Activation
OTAA
LoRaWAN® Class
Class A (default)
Configurable to Class C via Maya
LED
Status
LED Type
1 Internal Multi-Color LED
Solid Blue
Device is connected with Maya App
Flashing Blue
OTA (Over-the-Air) update in progress
Slow Blinking Green
Attempting to connect to the LoRaWAN® network
Single Red Blink
A confirmed parameter of MacSync is being modified
Device
Configuration
Configuration
Via Macnman Maya Android App
Uplink Modes
Time Based / Threshold Based / Sampling Based
Stored Records*
30,000 Records
Remote Configuration
JSON Format Data - from server
Battery
Performance
Battery Type
Li-SOCl₂ Cell (19Ah) Industrial grade
Power Consumption
~100 µA in sleep mode
~50 mA during transmission
Battery Life
Up to 10 years (10 Mins Uplink Interval)
Supported
LNS
Supports Major LNS
Private LNS
Chirpstack
The Things Networks
MQTT
Orbiwise
LORIOT
Direct PLC On-Prim Installations
Physical
Characteristics
Power Supply (Optional)
9-36 V DC
Operating Temperature
-40°C to +80°C
Humidity Range
0% to 100% RH (non-condensing)
Ingress Protection
IP65 standard (IP67 optional variant)
Housing Material
Glass field Nylon
Color
Matte White
Weight
~110g
Mounting Options
Pole Mounting / Wall Mounting
Electrical
Characteristics
Input Voltage Range (Optional Varient)
9-36 V DC (External Supply)
Power Consumption
~100 µA in sleep mode
~50 mA during transmission
Input Impedance
>10 MΩ for voltage inputs
Communication
Options
BLE Connectivity
For local configuration and diagnostics via Maya App
Cloud Protocols
MQTT / HTTPS / TCP IP (Gateway Dependent )
Serial Interface
RS485 Modbus RTU support (optional)
Certifications &
Compliance
WPC
Compliant
RoHS
Conforms to RoHS directive
Security &
Encryption
Data Encryption
AES-256 end-to-end encryption
Authentication
OTAA activation modes
Firmware Protection
Secure boot and signed OTA updates
MacSync-L-CO2X Variants
| Variant Name | CO₂ Range | Power Source | Battery Capacity | Ideal For |
|---|---|---|---|---|
| MacSync-L-CO2X1-PO | 400–2,000 ppm | External Power (9–36 V DC) | ✖️ | HVAC automation in commercial buildings with stable power |
| MacSync-L-CO2X1-BO | 400–2,000 ppm | Battery Powered | 19 Ah | Schools, offices & hospitals focused on IAQ compliance |
| MacSync-L-CO2X2-PO | 400–5,000 ppm | External Power (9–36 V DC) | ✖️ | Industrial & high‑density areas requiring extended CO₂ sensing |
| MacSync-L-CO2X2-BO | 400–5,000 ppm | Battery Powered | 19 Ah | Retrofit deployments, warehouses & logistics hubs |
What's in the box ?
Make sure box contains following items before installations
Accessories must be purchased separately & may not be included in the box.
Product Dimensions
