MacSync-LVX1 Datasheet
Product Overview
MacSync-LVX1 is an advanced LoRaWAN® vibration and condition monitoring sensor designed for predictive maintenance and continuous machine health diagnostics. Equipped with a high‑precision tri‑axis MEMS accelerometer, it monitors vibration amplitude, frequency spectrum, temperature, and shock events — enabling early detection of failures in motors, pumps, gearboxes, bearings, and rotating equipment.
Powered by long‑range LoRaWAN® connectivity and ultra‑low‑power architecture, MacSync‑LVX1 delivers real‑time asset health data across large industrial environments without requiring wired infrastructure. Its rugged IP67 enclosure, noise‑optimized sensing, and internal analytics ensure reliable operation in harsh and high‑vibration environments.
With secure AES‑encrypted communication, BLE onboard configuration via Maya App, OTA parameter updates, and intelligent event‑triggered reporting, MacSync‑LVX1 helps reduce downtime, avoid catastrophic failures, and extend equipment lifetime — making it an essential solution for Industry 4.0 predictive maintenance deployments.
Download Center
Download the PDF Version of the Datasheet .
Click here to view the decoders for MacSync-LVX1
Key Features
Tri‑Axis Vibration Monitoring High‑precision MEMS accelerometer enables comprehensive vibration analysis across all axes.
Predictive Maintenance Intelligence Detects anomalies in motors, pumps, gearboxes & bearings before failures occur — reducing downtime.
FFT & Frequency Spectrum Analysis Enables root‑cause fault detection for imbalance, looseness, misalignment & bearing wear.
Shock & Impact Event Detection Instant alerting for mechanical knocks, collisions & abnormal equipment behavior.
Onboard Temperature Monitoring Integrated thermal tracking improves fault diagnosis for motors & rotating assemblies.
Ultra‑Low‑Power LoRaWAN® Connectivity Multi‑year battery life with periodic, threshold & event‑driven reporting modes.
Rugged Industrial Design IP67 rating, vibration‑resistant build for continuous use in harsh industrial environments.
BLE Commissioning via Maya App Zero‑touch provisioning, diagnostics & OTA firmware updates on‑site.
Secure Data Communication AES‑encrypted uplinks ensure reliable & protected machine‑health telemetry.
Plug‑and‑Play Deployment Mounts easily on rotating equipment — no wiring required for battery model.
Suited Applications
Rotating Machinery Monitoring Continuous health diagnostics for motors, pumps, compressors, blowers, and turbines.
Bearing Condition Monitoring Detects wear, lubrication failure, and fatigue early to prevent catastrophic failures.
HVAC & Industrial Fans Identify imbalance, misalignment, and vibration escalation in ventilation and cooling systems.
Gearbox & Conveyor Systems Alerts for mechanical looseness, gear wear, and chain drive degradation in assembly lines.
Oil & Gas / Energy Sector Assets Remote equipment vibration diagnostics in hazardous or difficult‑to‑reach installations.
Predictive Maintenance in Smart Factories Enables condition‑based maintenance (CBM) and Industry 4.0 automation.
Structural Vibration & Machine Safety Suitable for cranes, presses, milling machines, heavy industrial rigs and material handling equipment.
Mining & Harsh Industrial Environments Rugged IP67 design ensures reliable monitoring under continuous vibration and dust exposure.
Remote Industrial Assets LoRaWAN® long‑range communication eliminates wired infrastructure requirements.
Technical Specification
General
Specifications
Part Order Number
MacSync-LVX1
Product Brand
Macnman Technologies Pvt Ltd
Vibration
Measurement
Measuring Parameters
Tri‑axis vibration and machine condition parameters
Vibration Output Data
RMS values (average)
Kurtosis
Crest Factor
Skewness
FFT High‑Energy Samples (Amplitude + Frequency)*
Velocity Measurement Range
0 to 100 mm/s
Accelerometer Type
Tri‑axis MEMS accelerometer
Acceleration Range
±16g
Sampling Bandwidth
5 Hz to 2500 Hz (±1 dB)*
Internal Sampling Frequency
Up to 2500 Hz for high‑resolution FFT
Shock Detection
High‑G peak detection with trigger‑based reporting
Built‑In Temperature Sensor
For thermal‑assisted mechanical failure diagnostics
Additional
Measurements
Ambient Temperature Range
-40°C to +85°C
Ambient Temperature Accuracy
±0.2°C @ 25°C
Ambient Temperature Resolution
0.01°C
Relative Humidity Range
0% to 100% RH
Relative Humidity Accuracy
±3% RH (@ 90% RH)
Relative Humidity Resolution
0.01% RH
Surface Temperature Range
-40°C to +80°C
Surface Temperature Accuracy
±2°C
Surface Temperature Resolution
0.01°C
Atmospheric Pressure Range
500–1100 hPa
Atmospheric Pressure Accuracy
±0.5 hPa @ 25°C
Atmospheric Pressure Resolution
0.1 hPa
Wireless
Transmission
Wireless Protocols
LoRaWAN® (v1.0.4)
Macnman MacTalk Protocol
Antenna
Internal high-efficiency antenna
Supported Bands
IN865 / RU864 / EU868 / US915 / AU915 / KR920 / AS923-1/2/3/4
Tx Power
23 dBm @ 868 MHz / 20 dBm @ 915 MHz / 19 dBm @ 470 MHz
Sensitivity
-137 dBm @ 300 bps
Activation
OTAA
LoRaWAN® Class
Class A (default)
Configurable to Class C via Maya
LED
Status
LED Type
1 Internal Multi-Color LED
Solid Blue
Device is connected with Maya App
Flashing Blue
OTA (Over-the-Air) update in progress
Slow Blinking Green
Attempting to connect to the LoRaWAN® network
Single Red Blink
A confirmed parameter of MacSync is being modified
Device
Configuration
Configuration
Via Macnman Maya Android App
Uplink Modes
Time Based / Threshold Based / Sampling Based
Stored Records*
30,000 Records
Remote Configuration
JSON Format Data - from server
Battery
Performance
Battery Type
Li-SOCl₂ Cell (19Ah) Industrial grade
Power Consumption
~100 µA in sleep mode
~50 mA during transmission
Battery Life
Up to 10 years (10 Mins Uplink Interval)
Supported
LNS
Supports Major LNS
Private LNS
Chirpstack
The Things Networks
MQTT
Orbiwise
LORIOT
Direct PLC On-Prim Installations
Physical
Characteristics
Power Supply (Optional)
9-36 V DC
Operating Temperature
-40°C to +80°C
Humidity Range
0% to 100% RH (non-condensing)
Ingress Protection
IP65 standard (IP67 optional variant)
Housing Material
Glass field Nylon
Color
Matte White
Weight
~110g
Mounting Options
Pole Mounting / Wall Mounting
Electrical
Characteristics
Input Voltage Range (Optional Varient)
9-36 V DC (External Supply)
Power Consumption
~100 µA in sleep mode
~50 mA during transmission
Input Impedance
>10 MΩ for voltage inputs
Communication
Options
BLE Connectivity
For local configuration and diagnostics via Maya App
Cloud Protocols
MQTT / HTTPS / TCP IP (Gateway Dependent )
Serial Interface
RS485 Modbus RTU support (optional)
Certifications &
Compliance
WPC
Compliant
RoHS
Conforms to RoHS directive
Security &
Encryption
Data Encryption
AES-256 end-to-end encryption
Authentication
OTAA activation modes
Firmware Protection
Secure boot and signed OTA updates
MacSync-LVX1 Variants
| Variant Name | Power Source | Battery Capacity | Solar Support | External Flash | Ideal For |
|---|---|---|---|---|---|
| MacSync-LVX1-PO | 12–24 V (Power) | ✖️ | ✖️ | ✔️ | Industrial or commercial sites with stable power supply |
| MacSync-LVX1-BO | Battery | 19 Ah | ✖️ | ✔️ | Remote or portable deployments with low power |
What's in the box ?
Make sure box contains following items before installations
Accessories must be purchased separately & may not be included in the box.
Product Dimensions
