MacSync-LT1 Datasheet
Product Overview
MacSync-LT1 is a premium LoRaWAN® temperature, humidity & pressure sensor, engineered for high-accuracy environmental monitoring in the most demanding industrial and outdoor deployments. Built for precision and longevity, it continuously captures real-time atmospheric data and transmits it over ultra-long-range LoRaWAN® networks—ensuring maximum uptime with minimal power consumption.
Powered by industrial-grade sensing elements and advanced thermal-isolation design, the MacSync-LT1 delivers fast response, low drift, and exceptional measurement stability even under harsh weather or mechanical stress. Its rugged enclosure and ingress-protected design make it a perfect fit for smart agriculture, cold chain logistics, HVAC automation, smart cities, warehouses, greenhouses, and remote environmental stations.
With support for LoRaWAN® v1.0.4, Class A operation, high-efficiency internal antenna, AES-256 encrypted communication, and optional BLE-based OTA configuration through the Maya App, deployment and maintenance become effortless and scalable for large industrial fleets.
Whether you’re modernizing legacy monitoring systems or delivering intelligent environmental analytics at scale, MacSync-LT1 provides a future-proof, carrier-grade, and low-maintenance sensing platform—transforming raw climate conditions into actionable intelligence for smarter decisions.
 |  |
|---|---|
 |  |
Download Center
Download the PDF Version of the Datasheet .
Click here to view the decoders for MacSync-LT1
Key Features
High‑Accuracy Sensing Precision temperature, humidity & barometric pressure measurement for reliable climate intelligence.
Industrial‑Grade Sensors Low drift, fast response, and long‑term measurement stability in harsh environments.
Ultra‑Low Power Operation Battery‑optimized LoRaWAN® Class A communication for multi‑year field deployments.
Smart Uplink Strategies Periodic reporting, threshold‑based triggers & event‑driven uplinks to reduce battery usage.
Secure Wireless Transmission AES‑128 encryption with OTAA activation for reliable, long‑range connectivity.
Ingress‑Protected Enclosure Designed for indoor and outdoor use — IP65 standard (IP67 optional).
BLE Configuration via Maya App Local setup, diagnostics, and OTA configuration using a smartphone.
Compatible with All LoRaWAN® Networks Works seamlessly with major public & private network servers.
Long‑Range Communication Robust LoRa coverage for agriculture fields, factories & remote outdoor sites.
Internal High‑Efficiency Antenna Optimized radiation pattern for long‑distance communication stability.
Compact & Lightweight Design Easy pole/wall mounting for permanent or temporary installations.
Future‑Proof Industrial IoT Ready Enables automated climate control & intelligent data analytics across industries.
Suited Applications
Smart Agriculture Environmental sensing for farms, greenhouses, vineyards, and horticulture climate automation.
Cold Chain Monitoring Reliable temperature & humidity tracking for warehouses, cold rooms, vaccine storage & food logistics.
Smart Buildings & HVAC Indoor air comfort and HVAC system efficiency monitoring in offices, malls & industrial buildings.
Environment & Weather Stations Pressure, temperature & humidity monitoring for micro‑climate analysis and air health.
Remote Infrastructure Climate exposure tracking for telecom towers, substations, wind turbines & solar plants.
Warehouses & Storage Rooms Ensures temperature/humidity‑controlled storage for pharma, FMCG & raw materials.
Industrial Automation Environmental influence analysis for manufacturing processes & equipment protection.
Smart Cities Distributed environmental sensing to support sustainability, safety & urban planning.
Mines, Tunnels & Harsh Sites Monitoring isolated industrial locations with long‑range LoRaWAN wireless coverage.
Technical Specification
General
Specifications
Part Order Number
MacSync-LT1
Product Brand
Macnman Technologies Pvt Ltd
Temperature
Measurement
Range
-30°C to +70°C
Accuracy
0°C to +70°C: ±0.3°C & -30°C to 0°C: ±0.6°C
Resolution
0.1°C
Calibration
Factory calibrated
Probe Options
Internal & External Both Options
Humidity
Measurement
Range
0% to 100% RH
Accuracy
10% to 90% RH: ±3% RH & <10% or >90% RH: ±5% RH
Resolution
0.5% RH
Calibration
Factory calibrated
Pressure
Measurement
Range
300 hPa to 1100 hPa
Accuracy
±1.0 hPa (typical at 25°C, 300–1100 hPa)
Resolution
0.1 hPa
Long‑Term Stability
≤ ±1 hPa/year
Calibration
Factory calibrated
Wireless
Transmission
Wireless Protocols
LoRaWAN® (v1.0.4)
Macnman MacTalk Protocol
Antenna
Internal high-efficiency antenna
Supported Bands
IN865 / RU864 / EU868 / US915 / AU915 / KR920 / AS923-1/2/3/4
Tx Power
23 dBm @ 868 MHz / 20 dBm @ 915 MHz / 19 dBm @ 470 MHz
Sensitivity
-137 dBm @ 300 bps
Activation
OTAA
LoRaWAN® Class
Class A (default)
Configurable to Class C via Maya
LED
Status
LED Type
1 Internal Multi-Color LED
Solid Blue
Device is connected with Maya App
Flashing Blue
OTA (Over-the-Air) update in progress
Slow Blinking Green
Attempting to connect to the LoRaWAN® network
Single Red Blink
A confirmed parameter of MacSync is being modified
Device
Configuration
Configuration
Via Macnman Maya Android App
Uplink Modes
Time Based / Threshold Based / Sampling Based
Stored Records*
30,000 Records
Remote Configuration
JSON Format Data - from server
Battery
Performance
Battery Type
Li-SOCl₂ Cell (19Ah) Industrial grade
Power Consumption
~100 µA in sleep mode
~50 mA during transmission
Battery Life
Up to 10 years (10 Mins Uplink Interval)
Supported
LNS
Supports Major LNS
Private LNS
Chirpstack
The Things Networks
MQTT
Orbiwise
LORIOT
Direct PLC On-Prim Installations
Physical
Characteristics
Power Supply(Optional)
9-36 V DC
Operating Temperature
-40°C to +80°C
Humidity Range
0% to 100% RH (non-condensing)
Ingress Protection
IP65 standard (IP67 optional variant)
Housing Material
Glass field Nylon
Color
Matte White
Weight
~110g
Mounting Options
Pole Mounting / Wall Mounting
Electrical
Characteristics
Input Voltage Range (Optional Varient)
9-36 V DC (External Supply)
Power Consumption
~100 µA in sleep mode
~50 mA during transmission
Input Impedance
>10 MΩ for voltage inputs
Communication
Options
BLE Connectivity
For local configuration and diagnostics via Maya App
Cloud Protocols
MQTT / HTTPS / TCP IP (Gateway Dependent )
Serial Interface
RS485 Modbus RTU support (optional)
Certifications &
Compliance
WPC
Compliant
RoHS
Conforms to RoHS directive
Security &
Encryption
Data Encryption
AES-256 end-to-end encryption
Authentication
OTAA activation modes
Firmware Protection
Secure boot and signed OTA updates
MacSync-LT1 Variants
| Variant Name | Power Source | Battery Capacity | Solar Support | External Flash | Ideal For |
|---|---|---|---|---|---|
| MacSync-LT1-PO | 12–24 V (Power) | ✖️ | ✖️ | ✔️ | Industrial or commercial sites with stable power supply |
| MacSync-LT1-BO | Battery | 19 Ah | ✖️ | ✔️ | Remote or portable deployments with low power |
What's in the box ?
Make sure box contains following items before installations
Accessories must be purchased separately & may not be included in the box.
Product Dimensions
