MacSync-L-RTDXx Datasheet
Product Overview
MacSync‑L‑RTDXx is a high‑precision LoRaWAN® RTD temperature monitoring device designed for industrial applications where accuracy, reliability, and long‑distance wireless communication are critical. Supporting both PT100 and PT100 sensors with IEC 60751 linearization, it ensures stable and precise temperature measurement across a wide operating range.
Engineered for harsh environments, the device features IP67 protection, surge‑resistant electronics, and rugged industrial‑grade construction suitable for pipelines, machinery, furnaces, cold‑chain systems, and process lines. With multi‑year battery life or optional DC power, the sensor is ideal for both fixed and remote installations.
MacSync‑L‑RTDXx supports event‑based alerts, configurable sampling, and BLE‑based field configuration using the Maya App. Using secure LoRaWAN® connectivity, data is transmitted directly to cloud dashboards, SCADA, CMMS, or any private/public LNS.
From industrial process control, predictive maintenance, HVAC monitoring, thermal safety compliance, to food & pharma cold‑chain assurance — MacSync‑L‑RTDXx delivers continuous and accurate visibility into temperature‑critical assets that keep industries running efficiently and safely.
 |  |
|---|---|
 |  |
Download Center
Download the PDF Version of the Datasheet .
Click here to view the decoders for MacSync-L-RTDXx
Key Features
High-Accuracy RTD Measurement Supports PT100 probes with IEC 60751 curve compensation for precise industrial sensing.
Wide Temperature Range Support Suitable for low- and high-temperature processes in industrial and commercial environments.
Long‑Range LoRaWAN® Connectivity Reliable wireless monitoring over several kilometers with minimal power consumption.
Multi‑Year Battery or DC Power Flexible power options for both remote deployments and fixed industrial installations.
IP67 Rugged Industrial Design Resistant to water, dust, corrosion, and vibration — suitable for outdoor and harsh environments.
Event‑Based Temperature Alerts Threshold‑based triggers help prevent overheating, freezing, and process deviations.
BLE Configuration via Maya App Quick local setup, diagnostics, and OTA updates through a smartphone interface.
Secure & Encrypted Data AES‑128 encrypted LoRaWAN® communication prevents unauthorized access and data tampering.
Compatible with All LoRaWAN® Networks Works seamlessly with public and private network servers, SCADA & cloud dashboards.
Predictive Maintenance Ready Enables early failure detection of pumps, bearings, motors & heat‑critical assets.
Suited Applications
Industrial Process Temperature Monitoring Continuous thermal measurement for chemical processing, metal fabrication, and industrial manufacturing.
Predictive Maintenance of Motors & Pumps Detects overheating in bearings, compressors, and rotating equipment to prevent unplanned downtime.
Boiler, Furnace & Heater Monitoring High‑temperature sensing for operational safety, combustion control, and regulatory compliance.
Cold‑Chain & Refrigeration Systems Real‑time temperature assurance in pharma, food, storage warehouses, and distribution trucks.
HVAC & Building Automation Smart thermal management for commercial infrastructure and energy efficiency optimization.
Oil & Gas Temperature Surveillance Rugged RTD monitoring for pipelines, well sites, and harsh‑environment assets.
Water & Pipeline Thermal Safety Monitors temperature in pipelines and distribution networks for freeze protection and quality control.
Laboratory, Pharma & Food Safety Ensures compliance in controlled environments and critical production processes.
Remote & Unmanned Plant Monitoring Low‑maintenance IoT deployments where wired sensors are costly or impractical.
Technical Specification
General
Specifications
Part Order Number
MacSync-L-RTDXx
Product Brand
Macnman Technologies Pvt Ltd
RTD
Measurement
Sensor Type
RTD (PT100 / PT100)
Temperature Range
–200 °C to +850 °C
Accuracy
±0.2 °C (typical)
Resolution
0.1 °C
Repeatability
±0.05 °C
Sensor Linearization
IEC 60751 Standard Curve
Self‑Heating Error
< 0.1 °C @ 1 mA excitation
Drift (1 year)
< 0.05 °C
Insulation Resistance
> 100 MΩ @ 500 VDC
Probe Options
Internal & External Probes Available
Probe Material
SS304 / SS316 (optional)
Wireless
Transmission
Wireless Protocols
LoRaWAN® (v1.0.4)
Macnman MacTalk Protocol
Antenna
Internal high-efficiency antenna
Supported Bands
IN865 / RU864 / EU868 / US915 / AU915 / KR920 / AS923-1/2/3/4
Tx Power
23 dBm @ 868 MHz / 20 dBm @ 915 MHz / 19 dBm @ 470 MHz
Sensitivity
-137 dBm @ 300 bps
Activation
OTAA
LoRaWAN® Class
Class A (default)
Configurable to Class C via Maya
LED
Status
LED Type
1 Internal Multi-Color LED
Solid Blue
Device is connected with Maya App
Flashing Blue
OTA (Over-the-Air) update in progress
Slow Blinking Green
Attempting to connect to the LoRaWAN® network
Single Red Blink
A confirmed parameter of MacSync is being modified
Device
Configuration
Configuration
Via Macnman Maya Android App
Uplink Modes
Time Based / Threshold Based / Sampling Based
Stored Records*
30,000 Records
Remote Configuration
JSON Format Data - from server
Battery
Performance
Battery Type
Li-SOCl₂ Cell (19Ah) Industrial grade
Power Consumption
~100 µA in sleep mode
~50 mA during transmission
Battery Life
Up to 8 years (10 Mins Uplink Interval)
Supported
LNS
Supports Major LNS
Private LNS
Chirpstack
The Things Networks
MQTT
Orbiwise
LORIOT
Direct PLC On-Prim Installations
Physical
Characteristics
Power Supply (Optional)
9-36 V DC
Operating Temperature
-40°C to +80°C
Humidity Range
0% to 100% RH (non-condensing)
Ingress Protection
IP65 standard (IP67 optional variant)
Housing Material
Glass field Nylon
Color
Matte Black
Weight
~110g
Mounting Options
Pole Mounting / Wall Mounting
Electrical
Characteristics
Input Voltage Range (Optional Varient)
9-36 V DC (External Supply)
Power Consumption
~100 µA in sleep mode
~50 mA during transmission
Input Impedance
>10 MΩ for voltage inputs
Communication
Options
BLE Connectivity
For local configuration and diagnostics via Maya App
Cloud Protocols
MQTT / HTTPS / TCP IP (Gateway Dependent )
Serial Interface
RS485 Modbus RTU support (optional)
Certifications &
Compliance
WPC
Compliant
RoHS
Conforms to RoHS directive
Security &
Encryption
Data Encryption
AES-256 end-to-end encryption
Authentication
OTAA activation modes
Firmware Protection
Secure boot and signed OTA updates
MacSync-L-RTDXx Variants
| Variant Name | RTD Type | Power Option | Ideal Use Case |
|---|---|---|---|
| MacSyncPT100‑PO | PT100 | 12–24 V DC Power | High‑precision temperature monitoring in automation systems |
| MacSyncPT100‑BO | PT100 | Battery (Multi‑year) | Cold‑chain, pipelines & predictive maintenance monitoring |
What's in the box ?
Make sure box contains following items before installations
Accessories must be purchased separately & may not be included in the box.
Product Dimensions
